Planmeca ProMax 2D S2
Standard Panoramic
ProMax Clinical Images
ProMax Clinical Images 3
ProMax Clinical Image 5
ProMax Clinical Image 6
ProMax Clinical Images 7
ProMax Clinical Images Sinus

Planmeca ProMax 2D S2

Product number: XXX

Planmeca ProMax 2D S2 is ideal for basic 2D needs and is easily upgradeable to 3D.

Read more
Request a costing Download PDF brochure

User interface provides guidance

The full-colour graphical user interface provides clear texts and symbols to guide you through your procedure. Settings are logically grouped and easy to understand, speeding up imaging and allowing you to focus on positioning your patient correctly and communicating with them.

Easy patient positioning

Open patient positioning and side entry minimise errors caused by incorrect patient positioning by allowing you to monitor the patient freely from both the front and side. Side entry allows easy access for all patients – standing or seated. Patient positioning is assisted by our triple laser beam system, which indicates the correct anatomical positioning points.

All the imaging programs you need

Our Planmeca ProMax® X-ray unit offers the widest variety of imaging programs available – easily meeting all your clinical needs. You can also select the correct exposure formats to minimise the radiation dose for all types of patients and diagnostic purposes.

Panoramic imaging

Standard panoramic program.

Extraoral bitewings

The Bitewing program uses improved interproximal angulation geometry. The result is a bitewing image pair with low patient dose and excellent diagnostic quality.

Sinus imaging

The Sinus programs provide a clear view of the maxillary sinuses.

Horizontal and vertical segmenting for panoramic program

With the Horizontal and vertical segmenting program, exposure can be strictly limited to the diagnostic region of interest. Patient dosage is reduced by up to 90% compared to full panoramic exposure.

TMJ imaging

The TMJ imaging programs produce lateral or posteroanterior views of open or closed temporomandibular joints. The imaging position can be adjusted to correspond to the anatomy of each individual patient. Child mode for reduced dose Child mode reduces the patient dose remarkably for all programs by reducing the imaging area and exposure values. In the panoramic program the focal layer can also be narrowed.

Easy upgrade from 2D to 3D

Planmeca ProMax® – future proof and a great investment

Planmeca ProMax® 2D is designed with upgradeability in mind. The unit’s modular structure allows easy conversion to different imaging modalities, while the software-driven SCARA is extremely flexible, allowing you to benefit from new imaging projections.

Whether you’re upgrading your 2D unit to 3D, or adding a cephalometric arm, Planmeca has the right solution for you. Individual options can be installed before delivery or added later, making Planmeca ProMax the most versatile all-in-one X-ray unit available.

  • Simple to use
  • Guided interface
  • Easy patient positioning
  • Side entry
  • All the imaging programs you need
  • Child mode for reduced dose
  • Easy upgrade from 2D to 3D
  • Planmeca ProMax, Digital Panoramic (SCARA2 arm) with GUI
  • 240V operating voltage
  • Wall support
  • Wall bracket assembly
  • Basic Panoramic Programmes
  • Planmeca Romexis 5 user 2D image licence
  • Data wall socket
  • Spiral cable
  • 3 year warranty
